20.09.2007 NEW MODEL: Grande Punto Abarth 1.4 turbo (155 hp) - technical specifications

Technical specifications: Grande Punto Abarth 1.4 turbo (155 CV)


4 cylinders in line, 4 valves per cylinder, 1368 cc
Power: 155 hp at 5500 min
Max torque 206 Nm at 5000 rpm (230 Nm at 3000 rpm in “sport” mode)
Drive-by-wire accelerator controls with no mechanical connection
Supercharged with IHI RHF3-P10.5 fixed geometry turbocharger.


6-speed gearbox
Dual hose external gearbox drive.

Suspension and steering

Front with McPherson strut and anti-roll bar
Torsion bar suspension at the rear

Grande Punto Abarth 1.4 turbo (155 hp)

The 4-cylinder 16v engine (1368 cc supercharged with an IHI fixed geometry turbocharger) delivers 155 hp at 5500 rpm with a maximum torque of 206 Nm at 5000 rpm.

Grande Punto Abarth 1.4 turbo (155 hp)

Developed by Abarth’s designers along with the technicians who produced the Grande Punto Fiat (one of Europe’s most successful cars), the Grande Punto Abarth is factory-built, and is subject to all the regulations and checks applied to standard models.

Lowered sports suspension
Electric power steering with “power boost” mode.


Fixed front caliper: Brembo M4x40, dual piston
Ventilated front brake disc ø 305 mm x 28 mm
Rear caliper with piston ø 54 mm
Rear brake disc ø 264 mm x 11 mm.


Deepened front and rear bumpers


Aluminium alloys, 7” x 17”
Tyres: 215/45-17
