2007 FRANKFURT IAA MOTOR SHOW

13.09.2007 FERRARI 430 SCUDERIA - TECHNICAL SPECIFICATIONS

FERRARI 430 SCUDERIA: Technical Specifications

Vehicle dimensions

Overall length 177.6 in (4512 mm)
Overall width 75.7 in (1923 mm)
Height 47.2 in (1199 mm)
Wheelbase 102.4 in (2600 mm)
Front track 65.7 in (1669 mm)
Rear track 63.6 in (1616 mm)
Dry Weight* 2775 lb (1250 kg)
Kerb Weight* 2975 lb(1350 kg)
Weight Distribution 43% Front, 57% Rear
Boot capacity 8.83 cu ft (250 l)
Fuel tank capacity 25.1 US gal (20.9 UK gal) (95 l)
Carbon-ceramic brakes: Front 15.6 x 1.4 in (398 X 36 mm), Rear 13.7 x 1.3 in (350 X 34 mm)
Tyres Front 235/35 19', Rear 285/35 19''

Engine

Type 90° V8
Bore and Stroke 3.26 x 3.19 in (92 x 81 mm)
Total displacement 263 cu in 4308 cm3
Compression ratio 11.88:1
Maximum power** 375.4 kW (510 CV) at 8500 rpm
Specific output 118.4 CV/litre
Maximum torque 470 Nm (346.67 lbft) at 5250 rpm
Maximum revs per minute 8640 rpm (with limiter)

Performance

Acceleration 0-62 mph (0-100 km/h) in less than 3.6 seconds


FERRARI 430 SCUDERIA

Ferrari engineers have removed a huge 100kg from their already athletic F430 berlinetta, providing the 430 Scuderia with a dry weight of only 1250 kg.

FERRARI 430 SCUDERIA

The new Ferrari 430 Scuderia is a special series based on the F430, and is aimed specifically at Ferrari’s most passionate and sports-driving oriented clients.


0-124 mph (0-200 km/h) in less than 11.6 seconds
0 - 1000 m in 20.9 seconds
Maximum Speed 198 mph (320 km/h)
Dry weight/Power 5.4 lb/CV (2,45 kg/CV)

Electronic Controls

CST Stability and Traction Control with new traction control logic F1-Trac integrated with the electronic differential (E-Diff)

Transmission and Gearbox

Electronic differential E-Diff2 (E-Diff + F1-Trac)
Gearbox F1, 6-gears + Reverse

Fuel Consumption

Combined* 15.7 l/100 km

CO2 Emissions

Combined* 360g/km

* European market version

** Engine power is expressed in kW, in accordance with the International System of Units (SI) and in CV for reasons of homogeneity. The horse power (hp) can be calculated as follows: 1 kW = 1.34 hp
