TECHNICAL
SPECIFICATIONS
|
|
ENGINE 1.4 -
8v - 77 bhp
No. of cylinders, arrangement 4, in line, front transverse.
No. of valves 2
Bore x stroke (mm) 72.0 x 84.0
Capacity (cc) 1368
Emissions compliance Euro Stage 4
Emissions control EOBD
Compression ratio 11:1
Max. power output: bhp-EC (kW-EC) 77 (57) at rpm 6000
Max. torque: kgm-EC (Nm-EC) 11.7 (115) at rpm 3000
Timing gear (control) 1 OHC with mechanical tappets
Fuel supply MPI phased sequential electronic
Ignition Static with digital electronic control
TRANSMISSION
Drive front
Clutch control hydraulic
Gearbox, no. of speeds 5
Gearbox: 1st 3.909 : 1; 2nd 2.158 : 1; 3rd 1.345 : 1
4th 0.974 : 1; 5th 0.829 : 1; Reverse 3.818 : 1; Gearbox
family C514; Final drive 4.500 : 1
STEERING
Type rack and pinion with hydraulic power steering
Turning circle (m) 10
BRAKES - D (disc) - T (drum)
Front: (mm) D 257 x 22 (ventilated); Rear: (mm) T 228 x 40
SUSPENSION
Front independent MacPherson type, telescopic dampers,
anti-roll bar with small con rods and spherical joint; Rear
torsion axle, telescopic hydraulic dampers
MEASUREMENTS
Wheelbase (mm) 2603; Front/rear track (mm) front 1473 / rear
1466; Length / Width / Height (m) 4560 / 1946 / 1494
Luggage capacity VDA (dm3) 500
WHEELS
Tyres 185/65 R15 - 195/60 R15; Optional 195/55 R16 - 205/45
R17
WEIGHTS - SUPPLIES
Weight ready for the road DIN (kg) 1160
front axle 1000; rear axle 900
Max. weight towable (kg)
unbraked 500
Fuel tank capacity (litres) 45
PERFORMANCE
Top speed (km/h) 165
Acceleration (sec.): 0 to 100 km/h 14.6; 0 - to 1000 m 36.2
EC CONSUMPTION (l/100 km)
as per EC Directive 1999/100; urban cycle 8.2; out of town
5.1; combined cycle 6.3
CO2 exhaust emissions (g/km) 148
|
 |
|
The
Fiat Linea receives its world première at the
Istanbul Motor Show last year. Turkey is the first
country the new sedan will be built in. |
|
|
 |
|
Luca
De Meo, Alì Aydin Pandir, Rahmi M. Koç and Alfredo
Altavilla with the Fiat Linea at the Istanbul Motor
Show last year. |
|
|
ENGINE 1.3 Multijet 16v, 90 bhp
No. of cylinders, arrangement 4, in line, front transverse
No. of valves 4
Bore x stroke (mm) 69.6 x 82.0
Capacity (cc) 1248
Emissions compliance Euro Stage 4
Emissions control EOBD
Compression ratio 17.6:1
Max. power output: bhp-EC (kW-EC) 90 (66) at rpm 4000
Max. torque: kgm-EC (Nm-EC) 20.4 (200) at rpm 1750
Timing gear (control) 2 OHC
rocker fingers with hydraulic tappets
Fuel supply Multijet Common rail direct injection with
variable geometry turbo and intercooler
Ignition by compression
TRANSMISSION
Drive front
Clutch control hydraulic
Gearbox, no. of speeds 5
Gearbox:
1st 4.273 : 1; 2nd 2.238 : 1; 3rd 1.444 : 1; 4th 1.029 : 1;
5th 0.767 : 1; Reverse 3.909 : 1; Gearbox family C510; Final
drive 3.733 : 1
STEERING
Type rack and pinion with hydraulic power steering
Turning circle (m) 10.85
BRAKES - D (disc) - T (drum)
Front: (mm) D 257 x 22 (ventilated); Rear: (mm) T 228 x 40
SUSPENSION
Front independent MacPherson type, telescopic dampers,
anti-toll bar with small con rods and spherical joint
torsion; Rear axle, telescopic hydraulic dampers
MEASUREMENTS
Wheelbase (mm) 2603; Front/rear track (mm) front 1473 / rear
1466; Length / Width / Height (m) 4560 / 1946 / 1494
Luggage capacity VDA (dm3) 500
WHEELS
Tyres 185/65 R15 - 195/60 R15; Optional 195/55 R16 - 205/45
R17
WEIGHTS - SUPPLIES
Weight ready for the road DIN (kg) 1185
front axle 1000
rear axle 900
Max. weight towable (kg) unbraked 500
Fuel tank capacity (litres) 45
PERFORMANCE
Top speed (km/h) 170
Acceleration (sec.): 0 to 100 km/h 13.8; 0 -to 1000 m 35.5
EC CONSUMPTION (l/100 km)
as per EC Directive 1999/100; urban cycle 6.5; out of town
4.0; combined cycle 4.9
CO2 exhaust emissions (g/km) 129 |
|
