Engine - Main features 2.0 JTS /2.0 JTS Selespeed

No. of cylinders, layout 4, in line, front transverse, 2 counter-rotating balancer shafts

Bore x stroke (mm) 83 x 91

Capacity (cc) 1970

Compression ratio 11.3 : 1

Max. power output EC: kW (bhp) 121 (165) at rpm 6400

Peak torque EC: Nm (kgm) 206 (21) at rpm 3250

Timing (control) 2 OHC, (toothed belt) with hydraulic tappets and electrohydraulic variable valve timing force-fitted on the inlet camshaft driven by a Bosch control unit

Fuel feed Bosch Motronic MED7.1.1 phased sequential electronic MPI with selective knock control

Ignition static, electronic digital combined with injection, knock sensor and 4 HT coils fitted in the head, 1 spark plug per cylinder

Emissions control Euro 4

CO2 emissions (g/km) 208

Electrical equipment (12V)

Battery: capacity (Ah) 60

Transmission

Drive front

Gearbox: 1st 3.909 : 1

2nd 2.238 : 1

3rd 1.520 : 1

4th 1.156 : 1

5th 0.946 : 1

Reverse 3.909 : 1

Final drive ratio 3.733 : 1

Wheels

Tyres 205/55 R16

205/55 ZR16

Steering

Steering box rack and pinion with power steering

Turning circle between kerbs (m) 11.5

Suspension

Front independent, dual wishbones with double trailing arm and anti-roll bar mounted on ball joints

Rear independent, MacPherson struts with transverse levers of different lengths anchored to an aluminium cross beam, reaction arms, offset coil springs, and anti-roll bar mounted on ball joints and linked to the shock absorber

Brakes D (disc)

Front: dia. (mm) D 284 (ventilated), Rear: dia. (mm) D 276

Bodywork - Dimensions

No. of seats / No. of doors 5 / 2

Length / Width (mm) 4489 / 1763, Height, unladen (mm) 1362, Wheelbase (mm) 2596, Front/rear track unladen (mm) 1524 / 1510

Boot capacity VDA (dm3) 320

Supplies - Weights

Fuel tank (litres) 63

DIN kerb weight (kg) 1320

Max. towable weight (kg) 1300

Performance - Fuel consumption

Speed with engine at 1000 rpm in 5th (km/h) 32.8

Top speed (km/h) 216

Acceleration (s)

(1 adult + 30 kg):

- 0 to 100 km/h 8.7

- 0 to 1000 m 29.2

Fuel consumption as per EC directive 1999/100 (l/100 km):

urban cycle 12.3

extra-urban cycle 6.8

combined cycle 8.7

Engine - Main features 3.2 V6

No. of cylinders, layout 6 in 60° V

Bore x stroke (mm) 93 x 78

Capacity (cc) 3179

Compression ratio 10 : 1

Max. power output EC: kW (bhp) 176 (240) at rpm 6200

Peak torque EC: Nm (kgm) 300 (30.6) at rpm 4800

Timing (control) 2 OHC, (toothed belt) with hydraulic tappets and electrohydraulic variable valve timing force-fitted on the inlet camshaft driven by a Bosch control unit

Fuel feed Bosch Motronic MED7.1.1 phased sequential electronic MPI with selective knock control

Ignition static, electronic digital combined with injection, knock sensor and 4 HT coils fitted in the head, 1 spark plug per cylinder

Emissions control Euro 4

CO2 emissions (g/km) 295

Electrical equipment (12V)

Battery: capacity (Ah) 60

Transmission

Drive front

Gearbox: 1st 3.500 : 1

2nd 2.253 : 1

3rd 1.520 : 1

4th 1.161 : 1

5th 0.971 : 1

6th 0.818 : 1

Reverse 3.545 : 1

Final drive ratio 3.733 : 1

Wheels

Tyres 225/45 ZR17

Steering

Steering box rack and pinion with power steering

Turning circle between kerbs (m) 11.5

Suspension

Front independent, dual wishbones with double trailing arm and anti-roll bar mounted on ball joints

Rear independent, MacPherson struts with transverse levers of different lengths anchored to an aluminium cross beam, reaction arms, offset coil springs, and anti-roll bar mounted on ball joints and linked to the shock absorber

Brakes D (disc)

Front: dia. (mm) D 330 (ventilated)

Rear: dia. (mm) D 276

Bodywork - Dimensions

No. of seats / No. of doors 5 / 2

Length / Width (mm) 4489 / 1763, Height, unladen (mm) 1355, Wheelbase (mm) 2596, Front/rear track unladen (mm) 1524 / 1510

Boot capacity VDA (dm3) 320

Supplies - Weights

Fuel tank (litres) 63

DIN kerb weight (kg) 1410

Max. towable weight (kg) 1400

Performance - Fuel consumption

Speed with engine at 1000 rpm

in 5th (km/h) 32.2

Top speed (km/h) 243

Acceleration (s) (1 adult + 30 kg):

- 0 to 100 km/h 6.7

- 0 to 1000 m 26

Fuel consumption as per EC directive 1999/100 (l/100 km):

urban cycle 18.6

extra-urban cycle 8.7

combined cycle 12.4

Engine - Main features 1.9 M-Jet 16v

No. of cylinders, layout 4, in line, front transverse

Bore x stroke (mm) 82 x 90.4

Capacity (cc) 1910

Compression ratio 18 : 1

Max. power output EC: kW (bhp) 110 (150) at rpm 4000

Peak torque EC: Nm (kgm) 305 (31) at rpm 2000

Timing (control) 2 OHC, (toothed belt) with hydraulic tappets, 4 valves per cylinder

Fuel feed Multijet direct injection with turbo and intercooler. Bosch EDC 16 electronic control system

Ignition by compression

Emissions control Euro 3 + EOBD

CO2 emissions (g/km) 178

Electrical equipment (12V)

Battery: capacity (Ah) 60

Transmission

Drive front

Gearbox: 1st 3.800 : 1

2nd 2.235 : 1

3rd 1.360 : 1

4th 0.971 : 1

5th 0.763 : 1

6th 0.614 : 1

Reverse 3.545 : 1

Final drive ratio 3.562 : 1

Wheels

Tyres 205/55 R16

Steering

Steering box rack and pinion with power steering

Turning circle between kerbs (m) 11.5

Suspension

Front independent, dual wishbones with double trailing arm and anti-roll bar mounted on ball joints

Rear independent, MacPherson struts with transverse levers of different lengths anchored to an aluminium cross beam, reaction arms, offset coil springs, and anti-roll bar mounted on ball joints and linked to the shock absorber

Brakes D (disc)

Front: dia. (mm) D 284 (ventilated)

Rear: dia. (mm) D 276

Bodywork - Dimensions

No. of seats / No. of doors 5 / 2

Length / Width (mm) 4489 / 1763, Height, unladen (mm) 1366, Wheelbase (mm) 2596, Front/rear track unladen (mm) 1524 / 1510

Boot capacity VDA (dm3) 320

Supplies - Weights

Fuel tank (litres) 63

DIN kerb weight (kg) 1365

Max. towable weight (kg) 1300

Performance - Fuel consumption

Top speed (km/h) 209

Acceleration (s) (1 adult + 30 kg):

- 0 to 100 km/h 9.6

- 0 to 1000 m 30.9

Fuel consumption as per EC directive 1999/100 (l/100 km):

urban cycle 8.7

extra-urban cycle 5.4
