Fiat Stilo Multi Wagon 1.6 16v |
Fiat Stilo Multi Wagon 1.8 16v |
| Engine |
1.6 16v |
1.8 16v |
| No. of cylinders, arrangement |
4, in line, front, transverse |
4, in line, front, transverse |
| Bore x stroke (mm) |
80.5 x 78.4 |
82.0 x 82.7 |
| Capacity (cc) |
1596 |
1747 |
| Compression ratio |
10.5 : 1 |
10.3 : 1 |
| Max. power output: kW-EC (bhp) |
76 (103) |
98 (133) |
| at rpm |
5750 |
6400 |
| Peak torque: Nm-EC (kgm) |
145 (14.8) |
162 (16.5) |
| at rpm |
4000 |
3500 |
| Timing (control) |
2 OHC (toothed belt), hydraulic tappets, 16v |
2 OHC (geared toothed belt), variable valve timing, with hydraulic
tappets, 16v |
| Fuel feed |
phased sequential electronic MPI with no-return system |
phased sequential electronic MPI with no-return system |
| Ignition |
electronic, state advance, combined with injection |
electronic, state advance, combined with injection |
| CO2 emissions (g/km) |
181 |
197 |
| Transmission |
| Drive |
front |
front |
Gearbox:
2st
3rd
4th
5th |
3.909 : 1
2.158 : 1
1.480 : 1
1.121 : 1
0.897 : 1 |
3.909 : 1
2.238 : 1
1.520 : 1
0.946 : 1
0.897 : 1 |
| Reverse |
3.818 : 1 |
3.909 : 1 |
| Final drive |
3.867 : 1 (58/15) |
3.867 : 1 (58/15) |
| Wheels |
| Tyres |
195/65 R15 91H |
195/65 R15 91V |
| Steering |
| Steering box |
electric power steering |
electric power steering |
| Turning circle between kerbs (m) |
10.5 |
11.1 |
| Suspension |
| Front |
independent MacPherson type with forged steel lower wishbones
anchored to an auxiliary crossmember, coil springs, dual rate telescopic
hydraulic shock absorbers and torsion bar |
| Rear |
interconnected wheel, coil springs, dual rate telescopic
hydraulic shock absorbers, axle with 2 longitudinal tubular elements and
open section torsion beam, torsion bar and controlled deformation hydraulic
blocks |
| Brakes D (disc) - ABS - EBD - ASR - MSR - Brake Assist
System* |
| Front: dia. (mm) |
D 257 (ventilated) |
D 284 (ventilated) |
| Rear: dia. (mm) |
D 251 |
D 251 |
| Bodywork - Dimensions |
| No. of seats / No. of doors |
5 / 5 |
5 / 5 |
| Length / Width (mm) |
4516 / 1756 |
4516 / 1756 |
| Height, unladen (mm) |
1570 |
1570 |
| Wheelbase (mm) |
2600 |
2600 |
| Front/rear track, unladen (mm) |
1514 / 1508 |
1514 / 1508 |
| VDA luggage capacity (dm3) |
510 ÷ 550 ÷ 1480 |
510 ÷ 550 ÷ 1480 |
| Supplies - Weights |
| Fuel tank (litres) |
58 |
58 |
| DIN kerb weight (kg) |
1298 |
1385 |
| Max. towable weight (kg) |
1100 |
1200 |
| Performance - Fuel consumption |
| Top speed (km/h) |
183 |
200 |
Acceleration (sec.)
(2 adults + 20 kg): 0 to 100 km/h
0 to 1000 m |
11.4
34.0 |
10.8
31.0 |
Consumption - 1999/100/EC directive (l/100 km)
- urban cycle
- extra-urban cycle
- combined cycle |
10.5
5.9
7.6 |
11.7
6.3
8.3 |
| optional on Actual versions |
| |
Fiat Stilo Multi Wagon 1.9 JTD 80 bhp |
Fiat Stilo Multi Wagon 1.9 JTD 115 bhp |
| Engine |
1.9 JTD |
1.9 JTD |
| No. of cylinders, arrangement |
4, in line, front, transverse |
4, in line, front, transverse |
| Bore x stroke (mm) |
82.0 x 90.4 |
82.0 x 90.4 |
| Capacity (cc) |
1910 |
1910 |
| Compression ratio |
18.45 : 1 |
18.45 : 1 |
| Max. power output: kW-EC (bhp) |
59 (80) |
85 (115) |
| at rpm |
4000 |
4000 |
| Peak torque: Nm-EC (kgm) |
196 (20.0) |
255 (26.0) |
| at rpm |
1500 |
2000 |
| Timing (control) |
1 OHC (toothed belt) |
1 OHC (toothed belt) |
| Fuel feed |
electronically controlled Unijet Common Rail direct injection, turbocharger |
electronically controlled Unijet Common Rail direct injection, variable
geometry turbo and intercooler |
| Ignition |
by compression |
by compression |
| CO2 emissions (g/km) |
149 |
149 |
| Transmission |
| Drive |
front |
front |
Gearbox: 1st
2nd
3rd
4th
5th |
3.909 : 1
2.238 : 1
1.520 : 1
1.156 : 1
0.919 : 1 |
3.577 : 1
1.887 : 1
1.192 : 1
0.848 : 1
0.686 : 1 |
| Reverse |
3.909 : 1 |
3.308 : 1 |
| Final drive |
3.053 : 1 (58/19) |
3.632 : 1 |
| Wheels |
| Tyres |
195/65 R15 91H |
195/65 R15 91H |
| Steering |
| Steering box |
electric power steering |
electric power steering |
| Turning circle between kerbs (m) |
10.5 |
10.5 |
| Suspension |
| Front |
independent MacPherson type with forged steel lower wishbones
anchored to an auxiliary crossmember, coil springs, dual rate telescopic
hydraulic shock absorbers and torsion bar |
| Rear |
interconnected wheel, coil springs, dual rate telescopic
hydraulic shock absorbers, axle with 2 longitudinal tubular elements and
open section torsion beam, torsion bar and controlled deformation hydraulic
blocks |
| Brakes D (disc) - ABS - EBD - ASR - MSR - Brake Assist
System* |
| Front: dia. (mm) |
D 284 (ventilated) |
D 284 (ventilated) |
| Rear: dia. (mm) |
D 251 |
D 251 |
| Bodywork - Dimensions |
| No. of seats / No. of doors |
5 / 5 |
5 / 5 |
| Length / Width (mm) |
4516 / 1756 |
4516 / 1756 |
| Height, unladen (mm) |
1570 |
1570 |
| Wheelbase (mm) |
2600 |
2600 |
| Front/rear track, unladen (mm) |
1514 / 1508 |
1514 / 1508 |
| VDA luggage capacity (dm3) |
510 ÷ 550 ÷ 1480 |
510 ÷ 550 ÷ 1480 |
| Supplies - Weights |
| Fuel tank (litres) |
58 |
58 |
| DIN kerb weight (kg) |
1395 |
1410 |
| Max. towable weight (kg) |
1300 |
1300 |
| Performance - Fuel consumption |
| Top speed (km/h) |
170 |
190 |
Acceleration (sec.)
(2 adults + 20 kg): 0 to 100 km/h
(2 adults + 20 kg): 0 to 1000 m |
13.8
36.0 |
11.2
33.0 |
Consumption - 1999/100/EC directive (l/100 km)
- urban cycle
- extra-urban cycle
- combined cycle |
7.5
4.6
5.6 |
7.5
4.56
5.6 |
| * optional on Actual versions |
| |
Actual |
Active |
Dynamic |
| EXTERIOR |
| Foglights incorporated in headlights |
S |
S |
S |
| Body-coloured electric door mirrors + demister |
S |
S |
S |
| Segmented glass electric sunroof (Sky Window) |
O |
O |
O |
| Alloy wheels and 205/55 R16 91V tyres |
O |
O |
O |
| Alloy wheels and 215/45 R17 tyres (chains cannot be fitted) |
O |
O |
O |
| 16" alloy spare wheel |
O |
O |
O |
| Aesthetic moulding on the tailgate |
- |
S |
S |
| Darkened second, third and rear window glazing |
S |
S |
S |
| Metallic paint |
O |
O |
O |
| INTERIOR |
| Front glass-holder |
S |
S |
S |
| Rear ventilation outlets |
S |
S |
S |
| Driver's seat with lumbar adjustment |
- |
- |
S |
| Driver's seat with lumbar and height adjustment |
S |
S |
S |
| Split (1/3 - 2/3), fold-down rear seat |
S |
S |
S |
| Sliding, reclinable rear seats |
O |
O |
O |
| Passenger seat fold-down table |
O |
O |
O |
| Front armrest with oddments compartment |
- |
- |
S |
| Rear armrest with oddments compartment integral glass-holder and luggage
access |
O* |
O* |
O* |
| Oddments compartment beneath driver's seat |
- |
- |
S |
| Heated/refrigerated glove box (when air conditioner present) |
S |
S |
S |
| Rear courtesy light |
S |
S |
S |
| Lighted mirrors on sunblind (passenger side) |
- |
- |
S |
| Rear ashtray |
- |
- |
S |
| Comfort pack (parking sensor, dusk sensors, rain sensor) |
O |
O |
O |
| Leather steering wheel + gear lever knob |
O |
O |
O |
| Leather steering wheel with radio controls (6 buttons) |
O |
O |
O |
| Leather steering wheel with radio/Connect controls (11 buttons) |
- |
- |
O |
| Leather upholstery |
O |
O |
O |
| FUNCTIONAL / ELECTRIC |
| Electric front windows with automatic device and anti-obstruction sensor |
S |
S |
S |
| Electrical passenger compartment air recirculation |
S |
S |
S |
| Central locking with deadlock (including fuel filler flap) |
S |
S |
S |
| Immobiliser with rolling code |
S |
S |
S |
| Front door puddle light |
S |
S |
S |
| Dualdrive (electric power steering) |
S |
S |
S |
| Steering wheel with height and axial adjustment |
S |
S |
S |
| My Car (car function customisation) and trip computer |
S |
S |
S |
| Instrumentation with one-colour multifunction ISTN |
S |
S |
S |
| Radio with tape player (4 x 35W, RDS, autoreverse, 6 speakers) |
O |
S |
S |
| Radio with CD player (4 x 35 W, RDS, 6 speakers) |
O |
O |
O |
| Radio with CD + MP3 player (4 x 35 W, RDS, 6 speakers) |
O |
O |
O |
| CONNECT NAV |
O |
O |
O |
| CONNECT NAV+ |
- |
- |
O |
| 260 Watt HI-FI system with 8 speakers and subwoofer |
O |
O |
O |
| CD changer in upper facia compartment |
O |
O |
O |
| Alarm |
O |
O |
O |
| Electric seats with memory |
- |
- |
O |
| Electric rear windows with anti-obstruction sensor |
O |
O |
S |
| Cruise control |
O |
O |
O |
| Cold climate pack |
O |
O |
O |
| Multifunction remote control |
S |
S |
S |
| Air conditioner |
O |
S |
S |
| Automatic dual zone climate control system with AQS |
O |
O |
O |
| Fix & Go multi-use compressor |
O |
O |
O |
| SAFETY |
| ABS + EBD |
S |
S |
S |
| ASR / MSR |
S |
S |
S |
| Brake Assist |
- |
- |
S |
| ESP |
O/S(1) |
O/S(1) |
O/S(1) |
| Multistage front airbags with SMART system |
S |
S |
S |
| Front sidebags |
S |
S |
S |
| Window-bags |
O |
O |
S |
| Front seat-belts with pretensioners, load limiter and fastening sensors |
S |
S |
S |
| Side and central rear 3-point seat-belts |
S |
S |
S |
| Rear sidebags |
- |
- |
O |
| Three rear height-adjustable head-restraints |
S |
S |
S |
| ISOFIX attachments for child seat (two on rear seat) |
S |
S |
S |
| Xenon headlights |
- |
- |
O |
S = standard
O = optional
- = not available
(1) standard on 1.8 16v
* only with sliding rear seat |
