| ENGINE |
1.2 Petrol |
1.9 D |
1.9 JTD |
| No. cylinders |
4, in line |
4, in line |
4, in line |
| Arrangement |
front, transverse |
front, transverse |
front, transverse |
| Capacity (cc) |
1242 |
1910 |
1910 |
| Max. power. EC: KW (bhp) |
44 (60) |
46 (63) |
59 (80) |
| at rpm |
5000 |
4500 |
4000 |
| Max. torque EEC: Nm (kgm) |
102 (10,4) |
118 (12,0) |
196 (20,0) |
| at rpm |
2500 |
2500 |
1500 |
| Fuel system |
integral electronic MPI |
indirect injection and electronic pump |
UNIJET direct injection electronically-controlled Common Rail with
turbo and intercooler |
| TRANSMISSION |
| Drive |
front |
front |
front |
| Gearbox: no. speeds |
5 + reverse |
5 + reverse |
5 + reverse |
| STEERING |
| Type |
rack and pinion |
rack and pinion with power steering |
rack and pinion with power steering |
| Turning circle (m) |
11 |
11 |
11 |
| BRAKES - D (disc) - T (drum) |
| Front, mm dia. |
D 257 ventilated |
D 257 ventilated |
D 257 ventilated |
| Rear, mm dia. |
T 228 |
T 228 |
T 228 |
| SUSPENSION |
| Front |
Independent MacPherson with lower wishbones and coil springs
antiroll bar and WET double-acting telescopic shock absorbers |
| Rear |
live axle with single longitudinal leaf spring |
| DIMENSIONS (mm) |
Short cab - Long cab |
Short cab - Long cab |
Short cab - Long cab |
| Wheelbase |
2718 |
2718 |
2718 |
| Length |
4400 |
4400 |
4400 |
| Width |
1665 |
1665 |
1665 |
| Unladen height |
1585 - 1544 |
1585 - 1544 |
1585 - 1544 |
| Load compartment: |
| Length |
1770 - 1472 |
1770 - 1472 |
1770 - 1472 |
| Max width |
1314 - 1314 |
1314 - 1314 |
1314 - 1314 |
| Width between wheelarches |
1090 - 1090 |
1090 - 1090 |
1090 - 1090 |
| Ground clearance (175/70 R14) |
605 - 605 |
605 - 605 |
605 - 605 |
| Ground clearance (175/80 R14) |
615 - 615 |
615 - 615 |
615 - 615 |
| Working volume (l) |
1100 - 800 |
1100 - 800 |
1100 - 800 |
| WHEELS |
| Tyres |
175/70/R14OPT 175/80 R14 no chains |
175/70/R14OPT 175/80 R14 no chains |
175/70/R14OPT 175/80 R14 no chains |
| ELECTRICAL EQUIPMENT (12V) |
| Battery capacity (Ah) |
40/50 |
60 |
60 |
| Alternator: max current (A) |
65/75 |
65/85 |
65/90 |
| WEIGHTS - CAPACITIES |
| Kerb weight (kg) |
1080 - 1100 |
1165 - 1185 |
1185 - 1205 |
| Gross Vehicle Weight (GVW) (kg) |
1785 |
1870 |
1890 |
| Payload (kg) |
705 - 685 |
705 - 685 |
705 - 685 |
| Static payload flap (kg) |
300 |
300 |
300 |
| Max. towable weight |
1000 |
1000 |
1000 |
| Fuel tank capacity (litres) |
58 |
58 |
58 |
| PERFORMANCE |
| top speed (km/h) |
145 |
148 |
163 |
| Acceleration (sec): 0-100 km/h |
18 |
18 |
15 |
