TECHNICAL SPECIFICATIONS


Engine 1.2 8v

No. cylinders, arrangement 4 cylinders, in line, front
Capacity (cc) 1242
Emission levels Euro 4
Compression ratio 9.8 : 1
Maximum power delivery 44 (60) kW (bhp***EC) at rpm 5000
Maximum torque 102 (10.4) Nm (kgm-EC) at rpm 2500
Timing system 1 OHC mechanical tappets (toothed belt), 2 valves/cylinder
Fuel system Multipoint electronic injection, phased sequential, integral with returnless ignition system
Fuel 95 octane unleaded fuel (RON)
Transmission
Drive front
Gearbox Manual
No. of speeds 5 (+ reverse): 1st 3.909 : 1; 2nd 2.158 : 1; 3rd 1.480 : 1; 4th 1.121 : 1; 5th 0.897 : 1; Final drive ratio 3.562 : 1
Wheels
Standard tyres 185/65 R14 86T
Steering system
Steering box
Turning circle 9.83
Suspension
Front Mac Pherson
Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 12; Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 945

Performance
Top speed (km/h) 153
Acceleration from 0 to 100 km/h in secs 16.8; Acceleration from 0 to 1000 m in secs 36.3
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 7.7/5.0/6.0
CO2 emissions (g/km) 142
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – effective power in brake horse power

Engine 1.4 8v

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1368
Emission levels Euro 4
Compression ratio 11.0 : 1
Maximum power delivery 57 (77) kW (bhp***EC) at rpm 6000
Maximum torque 113 (11.7) Nm (kgm-EC) at rpm 3750
Timing system 1 overhead camshaft with mechanical tappets (toothed belt), 2 valves per cylinder
Fuel system Multipoint electronic injection, phased sequential, integral with returnless ignition system
Fuel 95 octane unleaded fuel (RON)
Transmission
Drive front
Gearbox mechanical
No. of speeds 5 (+ reverse): 1st 4.100; 2nd 2.158; 3rd 1.480; 4th 1.121; 5th 0.897; Reversing light 3.818; Final drive ratio 3.438
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g
Turning circle 9,83
Suspension
Front Mac Pherson
Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 975
Performance
Top speed (km/h) 167 in 4th gear
Acceleration from 0 to 100 km/h in secs 13.5; Acceleration from 0 to 1000 m in secs 35.5
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 7.2/4.6/5.5
CO2 emissions (g/km) 130
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power

Engine 1.4 16v 6M

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1368
Emission levels Euro 4
Compression ratio 11.0 : 1
Maximum power delivery 70 (95) kW (bhp***EC) at rpm 5800
Maximum torque 128 (13.0) Nm (kgm-EC) at rpm 4500
Timing system 2 overhead camshafts with mechanical tappets (toothed belt), 4 valves per cylinder
Fuel system Multipoint electronic injection, phased sequential, integral with returnless ignition system
Fuel 95 octane unleaded fuel (RON)
Transmission
Drive front
Gearbox mechanical
No. of speeds 6 (+ reverse): 1st 3.545; 2nd 2.158; 3rd 1.480; 4th 1.121; 5th 0.921; 6th 0.766; Reversing light 3.818; Final drive ratio 4.071
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front Mac Pherson; Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 980
Performance
Top speed (km/h) 175 in 5th gear
Acceleration from 0 to 100 km/h in secs 10.9; Acceleration from 0 to 1000 m in secs 33.3
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 8.5/5.4/6.6
CO2 emissions (g/km) 155
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power

Engine 1.3 Multijet 16v 75 bhp

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1248
Emission levels Euro 4
Compression ratio 17.6 +/- 0.4 : 1
Maximum power delivery 55 (75) kW (bhp***EC) at rpm 4000
Maximum torque 190 (19.4) Nm (kgm-EC) at rpm 1750
Timing system 2 overhead camshafts (belt with rocker control), 4 valves per cylinder
Fuel system Direct injection Multijet Common Rail with electronic control unit, turbocharger and intercooler
Fuel diesel
Transmission
Drive front
Gearbox mechanical
No. of speeds 5 (+ reverse): 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767; Reversing light 3.909; Final drive ratio 3.353
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g


NUOVA LANCIA YPSILON
NUOVA LANCIA YPSILON
NUOVA LANCIA YPSILON
NUOVA LANCIA YPSILON


Turning circle 9.83
Suspension
Front Mac Pherson; Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440; Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1045
Performance
Top speed (km/h) 167 in 5th gear
Acceleration from 0 to 100 km/h in secs 14.5; Acceleration from 0 to 1000 m in secs 35.6
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 5.4/3.9/4.5
CO2 emissions (g/km) 117
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power

Engine 1.3 Multijet 16v 75 bhp DFN*

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1248
Emission levels Euro 4
Compression ratio 17.6 +/- 0.4 : 1
Maximum power delivery 55 (75) kW (bhp***EC) at rpm 4000
Maximum torque 190 (19.4) Nm (kgm-EC) at rpm 1750
Timing system 2 overhead camshafts (belt with rocker control), 4 valves per cylinder
Fuel system Direct injection Multijet Common Rail with electronic control unit, turbocharger and intercooler
Fuel diesel
Transmission
Drive front
Gearbox robotised sequential
No. of speeds 5 (+ reverse): 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767; Reversing light 3.909; Final drive ratio 3.353
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front Mac Pherson; Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1070
Performance
Top speed (km/h) 167 in 5th gear
Acceleration from 0 to 100 km/h in secs 14; Acceleration from 0 to 1000 m in secs 35.6
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 5.2/3.8/4.3
CO2 emissions (g/km) b
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power

Engine 1.3 Multijet 16v 90 bhp

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1248
Emission levels Euro 4
Compression ratio 17.6 +/- 0.4 : 1
Maximum power delivery 66 (90) kW (bhp***EC) at rpm 4000
Maximum torque 200 (20.4) Nm (kgm-EC) at rpm 1750
Timing system 2 overhead camshafts (belt with rocker control), 4 valves per cylinder
Fuel system
Direct injection Multijet Common Rail with electronic control unit, turbocharger and
intercooler
Fuel diesel
Transmission
Drive front
Gearbox mechanical
No. of speeds 5 (+ reverse); 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767
Reversing light 3.909
Final drive ratio 3.353
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front Mac Pherson; Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1045
Performance
Top speed (km/h) 175 in 5th gear
Acceleration from 0 to 100 km/h in secs 11; Acceleration from 0 to 1000 m in secs 33.8
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 5.4/3.9/4.5
CO2 emissions (g/km) 117
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power

Engine 1.3 Multijet 16v 90 bhp DFN*

No. cylinders, arrangement 4 cylinders, in line, front, transverse
Capacity (cc) 1248
Emission levels Euro 4
Compression ratio 17.6 +/- 0.4 : 1
Maximum power delivery 66 (90) kW (bhp***EC) at rpm 4000
Maximum torque 200 (20.4) Nm (kgm-EC) at rpm 1750
Timing system 2 overhead camshafts (belt with rocker control), 4 valves per cylinder
Fuel system
Direct injection Multijet Common Rail with electronic control unit, turbocharger and
intercooler
Fuel diesel
Transmission
Drive front
Gearbox robotised sequential
No. of speeds 5 (+ reverse): 1st 3.909; 2nd 2.238; 3rd 1.444; 4th 1.029; 5th 0.767; Reversing light 3.909; Final drive ratio 3.353
Wheels
Standard tyres 185/65 R14 86T**
Steering system
Steering box 51 mm/g
Turning circle 9.83
Suspension
Front Mac Pherson; Rear Torsion beam
Brakes
Front disc, diameter in mm 257 x 22 (ventilated); Rear drum, diameter in mm 203 x 38
Dimensions and weights
Length x width x height (mm) 3810 x 1704 x 1530; Wheelbase (mm) 2388; Front/rear track (mm) 1450/1440
Luggage compartment load capacity (dm3) 215 / 290
Fuel tank (litres) 47
Kerb weight (kg) 1070
Performance
Top speed (km/h) 175 in 5th gear
Acceleration from 0 to 100 km/h in secs 10.5; Acceleration from 0 to 1000 m in secs 33.8
Fuel consumption as per
EC 1999/100 litres/100 km
- urban cycle/extraurban cycle/combined cycle: 5.2/3.8/4.3
CO2 emissions (g/km) 114
* (‘Dolce Far Niente’) ** 195/55 R15 85H standard on Platino specification
***Bhp – Effective power in brake horse power
